The king pin, normally made out of metal, is the major pivot in the steering mechanism of a motor vehicle. The initial design was actually a steel pin on which the movable steerable wheel was attached to the suspension. In view of the fact that it could freely revolve on a single axis, it restricted the levels of freedom of motion of the rest of the front suspension. During the 1950s, the time its bearings were substituted by ball joints, more in depth suspension designs became available to designers. King pin suspensions are still used on various heavy trucks in view of the fact that they can carry a lot heavier weights.
New designs no longer restrict this particular apparatus to moving like a pin and nowadays, the term may not be utilized for an actual pin but for the axis around which the steered wheels pivot.
The kingpin inclination or otherwise called KPI is also called the steering axis inclination or likewise known as SAI. This is the definition of having the kingpin set at an angle relative to the true vertical line on most new designs, as viewed from the front or back of the forklift. This has a vital impact on the steering, making it likely to return to the centre or straight ahead position. The centre location is where the wheel is at its highest position relative to the suspended body of the forklift. The motor vehicles weight has the tendency to turn the king pin to this position.
The kingpin inclination also sets the scrub radius of the steered wheel, which is the offset amid projected axis of the tire's connection point with the road surface and the steering down through the king pin. If these points coincide, the scrub radius is defined as zero. Even though a zero scrub radius is possible without an inclined king pin, it needs a deeply dished wheel in order to maintain that the king pin is at the centerline of the wheel. It is more practical to incline the king pin and use a less dished wheel. This likewise supplies the self-centering effect.
