There are 4 sizes of hook type blade carriages rated by the fork carriage lifting capacity. Hook type blade carriages have been the same.
The carriage bar spacing utilized for Class 1 is something like thirteen inches and the Class 1 carriage is rated to carry loads up to 2000lbs. The Class 2 carriage is rated to carry loads as much as 5,500lbs with carriage bar spacing of 16 inches. Class III carriages are rated for loads as much as 10,000 lbs. The carriage bar spacing for this class is 20 inches. Class IV carriages are rated for cargo as much as 15,500 lbs. The carriage bar spacing used for this capacity is twenty five inches.
The carriages for pin type forks can be different depending on the manufacturer. Pin mounted tines can vary by the amount of offset between the tine eye and the tine. Carriage capacity would be determined by the carriage pin size and by the tine size.
